1 ) Maximum temperature resistance of insulator: 300C
2 ) Maximum operation temperature: 250C
3 ) Insulation Resistance: > =500 MΩ/DC 1000V
4 ) Breakdown Voltage: > = AC1500V/5S
5 ) Capacity Tolerance: +/-5%
6 ) Temperature range: -60C-250C continuous heating; Heating element: Available with either etched foil or wire-wound elements:
7 ) Dimension: Maximum 1.2m*Xm Minimun 15mm*15mm; Thickness 1.5mm(Thinnest 0.8mm, Thickest 4.5mm)Lead wire Length: Standard 130mm.
1 ) With backing PSA (Pressure Sensitive Adhesive or called self adhesive, self stick adhesive)
As 3M PSA
2 ) With vulcanization or curing and compression at high temperature and press
3 ) With spring and hole or eyelet
4 ) With clamps
1 ) Heating evenly, accurate and adjustable
2 ) various shapes, holes, cutouts, profiled watt densities and multiple voltages
3 ) Put heat exactly where it is required
4 ) High dielectric strength, flexibility, bendable and cost effectiveness.
5 ) Resistance to temperature extremes, moisture, weathering, radiation, fungus and chemical attack
6 ) Heat can be applied to the most complex shapes, geometries, curves and pipes conceivable
Without sacrificing efficiency or dependability.
7 )Easily bonded and/or mechanically mounted, even onto the curving surface.
Welcome custom in size,shape,wattage,voltage and temperature;
Free design is ready here for you.
Here following is some available value of our heaters for your reference:
|maximum temperature||250C momentary; 200C continuously|
Maximum width: 1.2m, maximum length: 10m
Any pad shape is available
|Thickness range||0.04 inch(one-layer)~0.12 inch(Double-layer) or 1mm(one-layer)~3mm (double layer)|
|Voltage range||Any AC or DC at any volts under 480v|
|Wattage range||0.01W/square cm ~3W/square cm or 0.05w/inch2 ~15w/inch2|
|Lead wire or Cable||Silicone rubber wire,or Teflon cord|
|Installation||Hooks, eyelets, Velcro or PSA|
1. thin, light, stick and flexible.
2. fast heat transfer, quick warming or heating and less power consumption.
3. good thermal conductivity and heating fast and contact heating
4. custom production and long lift span
5. non-toxic and waterproof is optional (General heaters: IP65 while waterproof heaters:IP68
